SEPPES SEPPES High Lift Garage Door
SEPPES High Lift Garage Doors maximize vertical wall space by extending the door’s upward travel before turning horizontal. Featuring insulated panels, smooth operation, and superior durability, they are ideal for warehouses, workshops, and high-ceiling industrial facilities.
- Maximize Vertical Space
- Smart Access Control
- Insulated & Secure
- Smooth & Intelligent Operation
- Teilen
high lift overhead door design
| Komponente | Standardspezifikation | Optional Configuration |
| Door Panel Material | 0.42mm color-coated steel sheet with polyurethane foam insulation (Density: 48 kg/m³) | 0.5mm color-coated steel, 0.7mm aluminum alloy, 0.5mm stainless steel |
| Türstärke | 40mm (finger-protection type), 50mm (non-finger-protection type) | 60mm, 80mm, 43+60mm thermal break panel |
| Wicket Door Size | 800 × 1800 mm (custom sizes available) | – |
| Surface Finish | Orange-peel embossed finish | Stucco finish |
| Tafelfarbe | White | Custom colors according to RAL chart |
| Tafelhöhe | 500 mm | – |
| Schienenmaterial | 2.0mm galvanized steel | – |
| Torsion Shaft | Ø60 × 2 mm | Ø82 spring steel shaft |
| Spring Service Life | Approx. 30,000 cycles | – |
| Antriebssystem | German FROG PUPIL motor with frequency inverter | – |
| Sicherheitsvorrichtungen | ① Spring break safety device ② Steel cable break protection ③ Track anti-drop device ④ Safety edge | – |
| Öffnungsmethode | Push-button / Remote control | – |
| Motorposition | Left side / Right side | Center mounted / Rear mounted |
| Windwiderstand | Class 11 wind load resistance | – |
| Emergency Operation | Manual chain hoist | – |
| Dichtungssystem | Triple EPDM rubber seals at bottom, top, and side edges | – |
| Lift Type | Standard Lift (Headroom ≥ 500mm) | High Lift (Headroom ≥ 500mm and greater than door opening height)Vertical Lift (Headroom > Door opening height + 50mm)Inclined Lift |
| Optionales Zubehör | Vision panels, pedestrian wicket door with vision panel (double-layer polycarbonate), pass-through vision panel (single-layer polycarbonate) | Glass vision panel |
high ceiling garage door highlight
High Lift Track Configuration
Unlike standard sectional doors, the high lift sectional door travels vertically for a greater distance before transitioning to the ceiling track, maximizing wall and ceiling utilization.
Reinforced Insulated Door Panels
Constructed with double-sided steel panels and a polyurethane foam core, the insulated overhead door offers thermal insulation, sound reduction, and energy efficiency.
Dual Torsion Spring System
High-strength torsion springs are designed for large overhead door approximately 30,000 operating cycles, ensuring long-term reliability in high-frequency applications.
Hochmodernes Steuerungssystem
Powered by a German FROG PUPIL variable-frequency motor, providing smooth acceleration and deceleration, enhanced safety, and extended component life.
high lift sectional door video
large overhead door FAQ
A high lift garage door travels vertically up the wall before turning horizontal, allowing better utilization of overhead space compared to standard lift doors.
A high lift overhead door is recommended when the building has additional headroom and requires maximum wall and ceiling space utilization.
3. Why do large overhead door require dual torsion springs?
Large and heavy high lift sectional doors place greater loads on the balancing system. Dual torsion springs improve weight distribution, safety, and operational reliability.
4. Are SEPPES high lift garage doors insulated?
Yes. SEPPES insulated overhead doors feature polyurethane-filled panels that provide excellent thermal insulation, energy efficiency, and sound reduction.
