SEPPES Commercial Freezer Coiling Door
Seppes as a leading cold storage doors manufacturer, this innovation merges an airtight zipper lock with a multi-layer insulated industrial freezer door curtain. Its patented dual-shaft drive allows high-speed operation up to 0.8m/s without traditional weights, facilitating high-frequency cycling. Featuring IP65 protection, heated tracks, and an integrated safety light curtain, it withstands temperatures down to -20°C, making it the ultimate replacement for outdated, slow-moving cold storage solutions.
- Patent Dual-Shaft High-Speed Drive
- Insulated Multi-Layer & Zipper Curtain
- Superior Thermal Stability
- Soft Bottom Edge High Speed Doors
- Self Repairing High Speed Doors
- share
commercial freezer door design
| Specification Item | Technical Details (Metric & Imperial Units) |
| Sturcture | Patent Dual-Shaft High-Speed Drive+Zipper type |
| Max Available Size | Width: 1250mm – 5000mm (approx. 49″ – 197″) Height: 1500mm – 5000mm (approx. 59″ – 197″) |
| Installation Space | Standard: 150mm (5.9 inches); Motor: 400mm (15.7 inches); Door Header: 500mm (19.7 inches) |
| Speed | 0.4 -0.8 m/s (1.3 to 2.6 feet/s). |
| Power Requirements | Motor Power: 220V, 0.75kW – 1.5kW, 50Hz. |
| Curtain | The curtain is reinforced with an internal PVC zipper design, ensuring tight sealing and durability during long-term usage. |
| Frame Material | Head Unit: 1.8mm 304 Stainless Steel.Tracks: Specialized high-strength Aluminum Alloy profiles. |
| Track System | Aluminum alloy guide rails with double-row PVC seals and integrated track heating elements. |
| Wind Resistance | Class 4. Features fiberglass internal wind-resistant ribs. Supports manual resetting after accidental de-tracking. |
| Safety Features | Infrared Safety Photocells: Dual-sided sensors detect obstacles. If an object is detected during closing, the door reverses to the fully open position and delays closing until the path is clear. |
| Protection Rating | IP54 Control Box (Compliant with national electrical safety standards). |
overhead door high speed door highlight
Patent Dual-Shaft High-Speed Drive
Insulated Multi-Layer & Zipper Curtain
Self Repairing System
industrial freezer doors video
coolroom doors FAQ
1. How does the zipper design improve the insulation of this cold storage doors manufacturer model?
The zipper lock creates a virtually airtight seal between the curtain and track, eliminating air convection, which is the most significant source of heat gain and energy loss in coolroom doors.
2. What is the benefit of the dual-shaft technology over traditional doors?
Traditional high-speed doors rely on bulky counterweights. Our patented dual-shaft drive eliminates the need for weights, reducing mechanical complexity, lowering maintenance, and allowing for much faster, smooth cycling.
3. Does the curtain self-repair if hit by a forklift?
Yes, the insulated zipper curtain is designed to release upon impact and automatically re-insert itself during the next opening cycle, significantly reducing downtime and repair costs.
4. Is the IP65 rating suitable for washdown environments?
Yes, the IP65 rating on the drive and control components makes them highly resistant to water jets from any angle, making this door ideal for food processing facilities and other washdown areas.
5. Can this industrial freezer door handle hundreds of cycles per day?
Absolutely. It is specifically built for high-frequency use in demanding coolroom doors applications, featuring a rugged drive and motor designed for thousands of daily cycles.
Contact engineers now！
Scan the QR code to get the best price and expert advice within 24 hours.
