SEPPES full view rolling door
SEPPES Full View Roll Up Door combines security, visibility, and modern architectural design in one solution. Built with durable aluminum or steel frames and transparent panels, it provides reliable protection while maintaining an open, welcoming appearance. Ideal for retail storefronts, commercial buildings, parking facilities, showrooms, and industrial entrances, the door delivers smooth operation, space-saving vertical opening, and enhanced natural visibility.
- High-security roll-up design with full-view visibility
- Suitable for retail, commercial, and industrial applications
- Optional motorized and smart access control integration
- share
see through roll up door Design
| Parameter | Specification |
| Installation Space | Minimum headroom: 690 mm (27.2 in) Minimum side room: 260 mm / 320 mm (10.2 in / 12.6 in) |
| Opening Speed | 0.6 – 2.5 m/s (2.0 – 8.2 ft/s) |
| Operating Frequency | Up to 800 cycles/day |
| Track Size | W260 mm / W320 mm × L250 mm (10.2 in / 12.6 in × 9.8 in) |
| Power Supply | 220V (Transformer available) |
| Motor Power | 0.75 kW (<129 ft²) 1.5 kW (129–258 ft²) 2.2 kW (>258 ft²) |
| Control System | German FROG PUPIL control system |
| Door Panel Thickness | Aluminum alloy: 0.7 mm (0.028 in) Total panel thickness: 40 mm (1.57 in) |
| Insulation Filling | Polyurethane foam, density 48 kg/m³ (3.0 lb/ft³) |
| Panel Height | 185 mm (7.3 in) (with sealing rubber strips) |
| Panel Color | Silver grey (customizable) |
| Track Material | 2.5 mm (0.098 in) galvanized steel, powder coated (dark grey) |
| Inner Guide Rail | 5.0 mm (0.20 in) aluminum alloy |
| Frame Material | Frame: 2.0 mm (0.079 in) galvanized steel Cover: 1.0 mm (0.039 in) galvanized steel |
| Vision Window (Optional) | Small window: 600 × 130 mm (23.6 × 5.1 in) Full-width: max 6000 mm (19.7 ft) |
| Safety Devices | Infrared sensor (Jietek brand) Safety bottom edge (Bollard brand) |
| Opening Methods | Standard: Push button Reserved: IO ports & RS485 for automation integration |
| Motor Position | Left / Right |
| Wind Resistance | Level 10 (~24.5–28.4 m/s / 55–63 mph) |
| Emergency System | Manual brake release; large doors require assisted lifting (e.g., forklift) |
| Parameter | Specification |
| Installation Space | Minimum headroom: 690 mm (27.2 in) Minimum side room: 260 mm / 320 mm (10.2 in / 12.6 in) |
| Opening Speed | 0.6 – 2.5 m/s (2.0 – 8.2 ft/s) |
full view roll up security door highlight
Durable & Insulated Door Panel
The door panel has a standard thickness of 40mm, crafted with double-sided aluminum alloy, treated with anodizing and organic coloring for enhanced durability and appearance. The 0.7mm aluminum single layer is filled with high-density polyurethane foam (48kg/m³), providing excellent thermal insulation and soundproofing. This robust design offers impact resistance ≥ 45kg/m and ensures finger safety, making it strong, durable, and energy-efficient. Available in multiple colors and customized thicknesses (40/50/80mm), it provides industrial-grade aesthetics with excellent insulation properties. (Patent pending)
Acrylic Vision Windows for Improved Lighting
The rapid roll doors comes with vision windows, constructed from high-strength acrylic panels, allowing for clear visibility and natural lighting. The windows are replaceable, making maintenance easier and more cost-effective.
Manual Emergency System
In case of a power failure, seppes high-performance rigid rolling door is equipped with a manual emergency switch that allows for easy opening and closing, ensuring continuous operation even during power outages. This reliable backup feature guarantees safety and uninterrupted workflow in critical situations.
Choose our Fast Aluminum Industrial Rolling Shutter Door for a perfect blend of safety, insulation, aesthetics, and dependability for your industrial needs.
high speed rigid door Video
Contact engineers now！
Scan the QR code to get the best price and expert advice within 24 hours.
